Diffuse Photoelectric Sensor 10-500mm Detection NPN/PNP Output 24V 100mA Red Light 635nm

Name: Diffuse Photoelectric Sensor 10500mm Detection NPNPNP Output 24V 100mA Red Light 635nm
Brand: KRONZ
Price: 1 USD

Wholesale Diffuse Photoelectric Sensor 10-500mm Detection NPN/PNP Output 24V 100mA Red Light 635nm from china suppliers

Brand Name : KRONZ

Model Number : BP18Y-D500N

Certification : CE

Place of Origin : Guangdong, China

MOQ : 1

Price : Negotiable

Payment Terms : T/T,Western Union,MoneyGram

Supply Ability : 10000 pieces per month

Delivery Time : 5-8 working days

Packaging Details : Polybag packing

Detection Distance : 10mm-500mm

Sensing Method : Direct Diffuse

Output Type : NPN (Open Collector)

Vibration Resistance : 10 to 55H

Power Supply : 18 VDC

Connection : 2 m cable

Contact Now

BP18Y-D500N Photoelectric Sensor Diffuse Reflective 10-500mm NPN/PNP Output <1ms 12-24VDC

The BP18Y-D500N is a direct diffuse photoelectric sensor offering a 10-500mm detection range. It features a high-speed <1ms response time for rapid object detection in automation and packaging applications.

This versatile sensor provides both NPN and PNP open-collector outputs (24V, 100mA) and is easily configured for Light-On or Dark-On operation via a control wire. The high-intensity 635nm red LED ensures reliable performance, even in challenging ambient light up to 30,000 lux sunlight.

Operating from a 12-24VDC power source, it includes key features like short-circuit protection and anti-interference. Built for industrial environments, it withstands temperatures from -10 to +55°C and significant vibration. The unit comes with a 2-meter cable for easy installation.

Feature	Speciication
Sensing Type	10 - 500mm
Part Number	BP18Y-D500N
Output Type	NPN open collector output
Indicator	LED
Ambient Temperature	-10 to +55℃ (non-freezing)
